TMT47504 Digital Multimeter

SKU: TMT47504 Category: Measuring Tools - Total

Description

Description

CATIII 1000V

CATIV 600V

Display True RMS 6000 Counts

Features,

Sound & Light indicator for both Non-Contact Voltage (NCV) + Live

Backlight and Flash Light Indicator

Input LED Indication

High Voltage Prompt

Diode Test

Continuity Test

Temperature

Data Hold

Low Battery Indicator

Specifications

voltage	DC: 600mV / 6V / 60V / 600V / 1000V ±(0.5% +3), AC: 600mV / 6V / 60V / 600V / 750V ±(0.8%+5)
current	DC: 600µA / 6mA / 60mA / 600mA / 10A ±(1.2% +3), AC: 600µA / 6mA / 60mA / 600mA / 10A ±(1.5% +3)
rated duty cycle	1%~95% ±(3.0% +3)
range	Frequency: 10Hz / 100Hz / 1000Hz / 10KHz / 100KHz / 1000KHz / 10MHz ±(1.0%+3)
reading	Capacitance: 10nF / 100nF / 1000nF / 10µF / 100µF / 1000µF ±(4.0%+5) / 10mF / 100mF ±(5.0%+5)
resistance	600? / 6k? / 60k? / 600k? ±(1.0% +3) / 6M? / 60M? ±(1.5%+3)
